Nano-Change | M8 Field-Attachable Connectors
Allows Easy Field Conversion to Threaded Connection Quick-Disconnect
Solder Connections for Reliability in Vibration Applications
Male and Female in Both Straight and 90° Versions
| MECHANICAL |
| Connector Face: |
| Body: |
| Coupling Nut: |
| Termination: |
| ELECTRICAL |
| Voltage Rating: |
| Amperage: |
| ENVIRONMENTAL |
| Protection: |
| Ambient Oper. Temp: |
| PA |
| PA |
| Nickel-Plated Brass |
| Solder Lugs; Accepts |
| Conductor to #20 AWG |
| 60V AC/ 75V DC |
| 4A |
| IP 67 |
| 32° TO 185° F (0° TO 85º C) |
Part Number Selector
| 3P | 4P | |
| FEMALE FACE VIEW |
 |
 |
| MALE FACE VIEW |
 |
 |
| VOLTAGE | 60V AC / 75V DC | 60V AC / 75V DC |
| CURRENT | 4A | 4A |
| CLICK ON A PART NUMBER FOR MORE OPTIONS | ||
| FEMALE | FIELD-ATTACHABLE CONNECTORS WITH 3.5-5.0mm (.137-.196"OD) CABLE FITTING | |
| STRAIGHT | N03FA03124 | N04FA03124 |
| 90° | N03FA04124 | N04FA04124 |
| MATING RECEP. | 4R3P06A27C300 | 4R4P06A27C300 |
| MALE | FIELD-ATTACHABLE CONNECTORS WITH 3.5-5.0mm (.137-.196"OD) CABLE FITTING | |
| STRAIGHT | N03MA03124 | N04MA03124 |
| 90° | N03MA04124 | N04MA04124 |
| MATING RECEP. | 4R3P00A27C300 | 4R4P00A27C300 |
