Mini-Change | Accessory Products
Closure Caps for Receptacles, Connectors, and Multi-Ports
Threaded Unions for Mating (2) Cordsets
Female and Male Plugs / 90° Adapters
| MECHANICAL |
| Closure Caps - Int. Threads: |
| Closure Caps - Ext. Threads: |
| Threaded Union: |
| LIQUID-TIGHT PLUGS |
| Connector Body: |
| Coupling Nut: |
| Clamp Nut: |
| Insert: |
| 90° Adapt. Connector Body: |
| Coupling Nuts: |
| Insert: |
| ELECTRICAL |
| LIQUID TIGHT PLUGS |
| Voltage Rating: |
| ENVIRONMENTAL |
| Protection: |
| Ambient Oper. Temp: |
| CERTIFICATIONS |
| UL: |
| CSA: |
| Gray Anodized Aluminum |
| Black Anodized Aluminum |
| Gray Anodized Aluminum |
| Zinc Plated Steel |
| Gray Anodized Aluminum |
| Zinc Plated Steel |
| PVC - UL STD 94 - V0 |
| Yellow Nylon |
| Zinc Diecast w/ Black Epoxy |
| PVC - UL STD 94 - V0 |
| 600V |
| Current: 2P - 13A |
| 3P - 10A |
| 4P - 8A |
| 5P - 8A |
| IP65, NEMA 4 |
| -4° TO 221° F (-20° TO 105° C) |
| UL Recognized File NO. E46237 |
| CSA Certified, File NO. LR6837 |
Part Number Selector
| CLOSURE CAPS & THREADED UNIONS | ||||
| DESCRIPTION | FOR USE WITH | 2P to 6P (Coupler Size: 1") |
6P to 8P (Coupler Size: 1 -1/8") |
9P to 12P |
| ALUMINUM CLOSURE CAP WITH INTERNAL THREADS |
MALE & FEMALE RECEPTACLES + MULTIPORT BASE UNITS |
65-0086 | 65-0103 | 65-0105 |
| ALUMINUM CLOSURE CAP WITH EXTERNAL THREADS |
MALE & FEMALE CONNECTORS |
65-0085 | 65-0102 | 65-0104 |
| ALUMINUM THREADED UNION |
MALE & FEMALE CONNECTORS |
55-0426 | 55-0466 | 55-0496 |
| CLICK ON A PART NUMBER FOR MORE OPTIONS | ||||
| MINI-CHANGE PLUGS WITH #16 AWG PVC LEADS 6'-0" LONG FOR 1/2" LIQUID TIGHT CONDUIT | ||||
| 2P | 3P | 4P | 5P | |
| FEMALE FACE VIEW |
 |
 |
 |
 |
| COLOR CODE | 1 - white 2 - black | 1 - green-gnd 2 - black 3 - white | 1 - black2 - white3 - red4 - green-gnd | 1 - white 2 - red 3 - green-gnd 4 - orange 5 - black |
| FEMALE | 40718 | 40925 | 41132 | 41344 |
| MALE | 40780 | 41037 | 51149 | 41593 |
| 90° ADAPTERS WITH (1) MALE PLUG AND (1) FEMALE PLUG | ||||
| 2P | 3P | 4P | 5P | |
| 90° | 40761 | 41048 | 41212 | 41481 |
